AWANSTOR® IX 4000 2U Series

Awanstor IX Network Attached Storage (NAS) Systems are built on super platform to provide rock solid reliability and up-time performance. Designed to provide extreme throughput from supported 10/40/100Gbps network interface cards combined for maximum performance to an excellent value for customers needing increased performance to support initiatives such as Virtualization, Archival, Video/Media, Financial services & Data Centers.

The Awanstor IX 4112-E3530 processors are designed with Intel® Xeon® E3 series processor with 4 processing cores delivering significant benefits in performance, power efficiency of 550W Single/Redundant Power Supply Virtualization and security. Our Data Storages are configured with memory in-terms of 8 GB DDR4 ECC installed, upgradeable upto 64GB DDR4 ECC UDIMM. IX 4112-E3530 supports maximum drives of 12 SAS/SATA3 3.5”/SAS 2.5” with multi-raid configurations, provides unbelievable expansion features with the addition of Disk Enclosures.

Product Specifications

Model# 4112-E3530
Form factor 2U Rack Mount
Bays 12 Hotswap
Drive size 12x3.5"/2.5"
CPU
Installed Intel Xeon E3 Quad Core Processor
Upgradeable N/A
Memory
Installed 8GB DDR4 ECC UDIMM
Upgradeable(Max) 64GB DDR4 ECC UDIMM
Network
Onboard 2x 1GbE
Upgradeable 2x 10GbE
Supported Disk type
Installed 3.5" SATA Enterprise HDD
Upgradeable 3.5" Nearline SAS 6/12 Gbps/2.5" Enterprise SAS
RAID Level RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60
File Sharing Windows(CIFS/Samba3), Linux(NFSv3,v4), Mac (AFP)
Manageability Command Line & Web Interface Management
Data Management Quota, Thin & Thick Volume, Clone, Compression & Dedupe
Data Protection Unlimited Snapshots, Remote Replication, Rsync
Caching Inline Compression, Inline Dedupe
Authentication Local User, LDAP & Active Directory
Power supply Single/RPS 550W
Expansion
Controller Single
Capacity ** Contact us for details
Filesystems Unlimited
Files Unlimited
Platforms Supported
Linux OS Ubuntu, Debian, CentOS/RHEL, Fedora, OpenSUSE/SLES
Windows Windows 7/8.1/10, Windows Server 2008/2012/2016
Apple Mac OS X 10.x
