Awanstor Systems are built on super platform to provide rock solid reliability and up-time performance. Designed to
provide extreme throughput from supported 10/40/100Gbps network interface cards combined for maximum
performance to an excellent value for customers needing increased performance to support initiatives such as
Virtualization, Archival, Video/Media, Financial services & Data Centers.
The Awanstor IX 4012-2U designed with Intel® Xeon® Processor E5-2600 v4 series processor with 4 processing cores delivering significant benefits in performance, power efficiency of 1200W RPS, Virtualization and security. Our Data Storages are configured with memory in-terms of 16 GB DDR4 ECC installed, upgradeable upto 2TB DDR4 ECC LRDIMM RAM. Awanstor IX 4012-2U supports maximum drives of 12 SAS/SATA3 3.5”/SAS 2.5” with multi-raid configurations. By adding disk enclosures storage capacity can be expanded upto 1 PetaByte.
| Model# 4224-e5409 |
| Form factor |
2U Rack Mount |
| Bays |
12 Hotswap |
| Drive size |
12 x 3.5"/2.5"
|
|
| CPU |
| Installed |
Intel Xeon E5 Processor |
| Upgradeable |
N/A |
|
| Memory |
| Installed |
8GB |
| Upgradeable(Max) |
2TB |
|
| Network |
| Onboard |
2x1GbE |
| Upgradeable |
2x10GbE/40GbE |
|
| Supported Disk type |
| Installed |
3.5" Enterprise SATA 6Gbps |
| Upgradeable |
2.5" Nearline SAS 6/12 Gbps.2.5" Enterprise SAS, SSD, NvMe |
|
| RAID Level |
RAID0, RAID1, RAID5, RAID6, RAID10, RAID50, RAID60 |
| File Sharing |
Windows(CIFS/Samba3), Linux(NFSv3,v4), Mac (AFP) |
| Manageability |
Command Line & Web Interface Management |
| Data Management |
Quota, Thin & Thick Volume, Clone, Compression & Dedupe |
| Data Protection |
Unlimited Snapshots, Remote Replication, Rsync |
| Caching |
Inline Compression, Inline Dedupe |
| Authentication |
Local User, LDAP & Active Directory |
| Power supply |
RPS 650W |
| Expansion |
| Controller |
Single |
| Capacity |
Unlimited, * Max 1.4 PB using Awanstor JB 4U Expansion |
| Filesystems |
Unlimited |
| Files |
Unlimited |
|
| Platforms Supported |
| Linux OS |
Ubuntu, Debian, CentOS/RHEL, Fedora, OpenSUSE/SLES |
| Windows |
Windows 7/8.1/10, Windows Server 2008/2012/2016 |
| Apple |
Mac OS X 10.x |
|
